Lowrance Eagle 7″ with Triple Shot Transducer

Eagle 7 was born to make fishing as simple and enjoyable as possible. Easy to use and quick to install, this model features newly designed TripleShot™ HD Transducer with FishReveal technology and autotuning for a quick and optimal set up. A new IPS screen provides higher resolution and visibility from all angles. This model comes pre-loaded with a worldwide basemap chart, and the option to upgrade to CMAP® DISCOVER™.

Give yourself the best chance of finding fish with underwater views to the side and below the boat, all in one transducer. TripleShot HD features the fish-finding capability of wide-angle high CHIRP sonar and the high-resolution images of fish-holding structure from SideScan and DownScan Imaging™.

More information on the Eagle 7 here.

Read More

Pickup Availability:

Malta
(Out of Stock)
€549

Out of stock

Check Lead Time

Notify when available

Enter your email address below and we'll notify you when this product is back in stock!

Features

  • Enhanced TripleShot™ HD Transducer with Autotuning sonar
  • Worldwide Basemap
  • IPS screen, viewable from all angles, even in polarized glasses
  • New reliable twist-lock connector system for easy installation in any boat or kayak
  • SD card slot for software updates, Genesis Live recording and charting add-ons.
  • See fish hiding in cover with FishReveal™ mode
  • Increase contrast and viewability with all-new Imaging color palettes

Specifications

Display
  • Backlight – ColorPure white LED
  • Display Resolution – 800 x 480
  • Display Size – 7 inches
  • Screen Brightness – 1000 NITS
  • Viewing Angles – 80° top/bottom, 80° left/right



Connectivity
  • SD Card Storage – 1 slot (microSD® 32 GB maximum)

Cartography
  • Charts supported – C-MAP® DISCOVER™.

Electrical
  • Power Consumption max – 550 mA @ 12 V DC with backlight on full
  • Power Consumption min – 250 mA @ 12 V DC with backlight off
  • Power Consumption typical – 550 mA @ 12 V DC with backlight on full
  • Recommended Fuse Rating – 3A
  • Supply Voltage – 12v DC (10.8-17VDC)



Environment
  • Humidity – 60°C, 95% relative humidity (RH) for 48 hours
  • Operating Temperature Range – 5°F to 131°F (-15°C to 55°C )
  • Storage Temperature Range – 4°F to 140°F (-20°C to 60°C )
  • Waterproofrating – IPX7 with card door closed



Physical
  • Compass Safe – 12″ (300mm)
  • Dimensions – W x H x D225.9 mm (8.89″) x 139.8 mm (5.5″) x 88.5 (3.48)
  • Mounting Type – Gimbal bracket or dash mount
  • Weight – 0.67 kg (1.48 lb)

Description

Eagle 7 was born to make fishing as simple and enjoyable as possible. Easy to use and quick to install, this model features newly designed TripleShot™ HD Transducer with FishReveal technology and autotuning for a quick and optimal set up. A new IPS screen provides higher resolution and visibility from all angles. This model comes pre-loaded with a worldwide basemap chart, and the option to upgrade to CMAP® DISCOVER™.

Give yourself the best chance of finding fish with underwater views to the side and below the boat, all in one transducer. TripleShot HD features the fish-finding capability of wide-angle high CHIRP sonar and the high-resolution images of fish-holding structure from SideScan and DownScan Imaging™.

More information on the Eagle 7 here.
