Wurth Hexagonal Bolt w/ Thread up to the Head M5

Article No. 0091520
ISO 4017 stainless steel A4 50, A4 70, plain SCR-HEX-ISO4017-A4/70-WS8-M5X20





Read More

Pickup Availability:

Malta
(Out of Stock)
  • 20mm 20mm
  • 25mm 25mm
  • 30mm 30mm
  • 40mm 40mm
  • 50mm 50mm
€0

Features

Thread type x nominal diameter (d1) M5
Length (l1) 20 mm
Head height (k1) 3.5 mm
External drive (s1) WS8
Standards ISO 4017
Material Stainless steel A4
Property class 70
Surface Bare
RoHS-compliant Yes
Head type Hexagon head
Drive type Outer hexagon
Thread type Metric thread
Thread format Standard metric thread
Thread design Full thread
Product class A

Specifications

ISO 4017 stainless steel A4-50 and A4-70, plain
Notice

ISO 4017 replaces DIN 933 | There is some compatibility | Nominal size extended | Widths across flats for M10, M12, M14 and M22 changed. Strength A4-70 up to and including nominal size M24 | From nominal size M27 strength A4-50
